1000w Power Inverter
  • 1000w Power Inverter1000w Power Inverter
  • 1000w Power Inverter1000w Power Inverter
  • 1000w Power Inverter1000w Power Inverter
  • 1000w Power Inverter1000w Power Inverter

1000w Power Inverter

KOSUN off grid modified sine wave 1000w power inverter pass the certifications:CE/LVE/RoHS/E-mark/SAA/IATF16949/REACH report to meet the market standard.

Send Inquiry

Product Description

KOSUN single phase modified sine wave 1000w power inverter have several protections.

The protection feature(12V input inverter sample):

Input low voltage protection:

When the battery voltage is below 10.5± 0.5V,a buzzer will alarm which indicates DC power supply voltage is descending and batteries need to recharge;

When input voltage is below 10.0±0.5v,AC output will be automatically shut off,a buzzer alarm and ALARM/WARNING light turns red at the same time.

Input over voltage protection:

When input voltage reach 16.0v±0.5v,ALARM/WARNING light turns red and the AC output will be shut off automatically.

Short Circuit protection:

When short circuit occur,output will be shut off and ALARM/WARNING light turns red.

Over load protection:

When overloads occur,output will be shut off and ALARM/WARNING light turns red.

Reverse polarity protection:

When battery terminals are reverse connected,fuse will be burned to protect appliances.

Over temperature protection:

When heat sink temperature exceeds 45℃,the inner cooling fan will automatically turn on to cool the inverter;

When inner temperature exceeds 75℃,AC output will automatically shut off,ALARM/WARNING light turns red.It is unusable for 15 minutes.


Product parameter(Specification) of the 1000w power inverter

Modified Sine Wave Inverter

■ Modified sine wave output;
■ High surge power up to 2 times of real loading power;
■ Loading 1.5times rated power for 10s,2times for 2s;
■ High efficiency up to 92%;
■ Power ON-OFF switch;
■ Soft start;
■ Built-out fuse;
■ More stable working functions
■ Front panel indicator for operation status;
■ Thermostatically and load controlled cooling fan;
■ Protections:Bat. low alarm/Bat. low shutdown/Bat. over shutdown/output short/input reverse protection/overload/over Temp.
■ 18 months wattanty

MODEL


KS1000M-112

KS1000M-124

KS1000M-148

KS1000M-212

KS1000M-224

KS1000M-248

OUTPUT

RATED POWER

1000W

SURGE POWER

2000W

AC VOLTAGE

Factory setting set at 100V/110V/120V AC

Factory setting set at 220V/230V/240V AC

FREQUENCY

50Hz/60Hz optional

WAVE FORM

Modified sine wave

AC REGULATION

±10%

STANDARD RECEPTACLES

Schuko/UK/Australia/Universal/USA/France/JP/Brazile

FRONT PANEL INDICATOR

Operation and fault status

INPUT

BAT.VOLTAGE

12V

24V

48V

12v

24V

48V

VOLTAGE RANGE

9.7-16.4VDC

19.4-32.8VDC

38.8-65.6VDC

9.7-16.4VDC

19.4-32.8VDC

38.8-65.6VDC

DC CURRENT

100A

50A

25A

100A

50A

25A

NO LOAD CURRENT DRAW

<0.32A

<0.25A

<0.2A

<0.32A

<0.25A

<0.2A

EFFICIENCY

89%

>90%

92%

88%

90%

91%%

BATTERY TYPES

Recommend use Open & sealed lead acid battery

BATTERY INPUT PROTECTION

BAT.LOW ALARM

10.8±0.3V

21.6±0.6V

43.2±1.2V

10.8±0.3V

21.6±0.6V

43.2±1.2V

BAT.LOW SHUTDOWN

10±0.3V

20±0.6V

40±1.2V

10±0.3V

20±0.6V

40±1.2V

BAT.OVER SHUTDOWN

16±0.4V

32±0.8V

64±1.6V

16±0.4V

32±0.8V

64±1.6V

REVERSE POLARITY

yes

OUTPUT PROTECTION

OVER TEMPERATURE

≥45ºC or ≥60% rated power, cooling fan open;≥70ºC,Shut off.

Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor

OUTPUT SHORT

Protection type:Shut down o/p voltage;re-power on to recover

OVER LOAD

100%-120% rated load for 10 sec.

Protection type : Shut down o/p voltage, re-power on to recover; by internal Thermistor detect on heatsink of power transistor

ENVIRONMENT

WORKING TEMP.

-15℃~+40℃@100% load;60℃ @50% load

WORKING HUMIDITY

20%90% RH non-condensing

STORAGE TEMP.

-30℃~+70℃/-22~+158℉

STORAGE HUMIDITY

10%95% RH non-condensing

SAFETY

CE

Compliance to EN55032

LVD

Compliance to EN60950-1

ROHS

Compliance to EN50581

E-MARK

E13

OTHERS

ISO9001/IATF16949/BSCI

UL test

B08H52NN2M/ B08H54PCDT/ B08H4TMTJC/ B08H51DTM8

REACH

No.:1907/2006

certificate of registration

IATF 16949:2016

111458/A/0001/SM/En

OTHERS

USB port

5V/2.1A

DIMENSION L*W*H (mm)

210*150*70

PACKING(cm)

42*34*45 ;6pcs/CTN,15.4KG


Product feature and application of the 1000w power inverter

①. Fuse:built-out;

②. USB:5V/2.1A;

③. Modified sine wave output;

④. High reliability and high efficiency;

⑤. High load ability;

⑥. Temperature Controlled Cooling Fan;

⑦. Protection:Overload.Short Circuit,Reverse Polarity,Over/Under Input Voltage,Over Temperature;

⑧. LED Indicator light indicate inverter,fault mode;

⑨. CE/RoHS/E-Mark/ISO9001 approved.


Product Qualification of the power inverter

A. CE Compliance to EN55032

B. TUV:AE50510684 0001

C. RoHS Compliance to EN50581

D. LVD Compliance to EN60950-1

E. E-Mark E13

F. IATF 16969

G. REACH/UL/TUV report


Deliver,Shipping And Serving of the power inverter

It is a flexible transportation for the power inverter to clients such as express/train/ocean/air etc which could meet different customers choice.The factory manage the materials in advance after confirming the order,and then,produce the cargoes which save more time for the whole process.KOSUN inverter pack with customized color box or neutral packages according to the customer demands.


FAQ

A. What character of the manufacture?

KOSUN are one of professional manufacture with two factories built in 2011 which equip with advanced auto-machine and modern assembly line for the standard process of produce,the products are more stable for the long time operation.The main products include pure sine wave inverter,inverter with charger,modified sine wave inverter,battery charger and power station etc,thus,welcome to negotiate with us for more information you want.

B. Why your quotation is higher than other suppliers?

C. In domestic market, the high and low inverter brands are mixed together. There are many low-cost inverter is actually some assembled small unlicensed workshops, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable inverter;

D. Is the output voltage of our inverter stable ?

E. Absolutely. Our inverter is designed with a good regulator circuit. You can even check it when measuring the true value by a multimeter. Actually the output voltage is quite stable;

F. What is a resistive load appliances?

G. Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully.

H. What is the inductive load appliances?

I. It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them.


The advantages to choose our team:

1. Our sales staff has extensive sales experience through continuous training and practice which they have the ability to efficiency cooperate development between company and clients and provide satisfied service to customers;

2. The company buy modern equipment for automated production line;

3. Training professional technical staff is essential process to improve the quality of produce;

4. Meeting before order production determine relative details to reduce error output;

5. Strict quality control(incoming inspection/semi-finished product inspection/finished product test/several times full test on-line/sampling test before shipment);

6. OEM/ODM accept by workshop;

7. Good after-sales service for long-term development.





Hot Tags: 1000w Power Inverter, Manufacturers, Wholesale, Factory, Customized, Bulk, China, Suppliers, Made in China, CE, Newest, Quality, Advanced, Latest Selling, Discount, Price List, 2 Years Warranty
